Request Routing in Magento 2

In the article, we’re going to compare routing in Magento 1 and Magento 2. Actually, there’s an article containing routing description in Magento 1, so in case you’d like to have a closer look at routing in Magento 1, read our blog.

Route determination starts from searching for current route defined in the system. The process starts here:

/vendor/magento/framework/App/FrontController.php

public function dispatch(RequestInterface $request)
    {
        \Magento\Framework\Profiler::start('routers_match');
        $routingCycleCounter = 0;
        $result = null;
        while (!$request->isDispatched() && $routingCycleCounter++ < 100) {
            /** @var \Magento\Framework\App\RouterInterface $router */
            foreach ($this->_routerList as $router) {
                try {
                    $actionInstance = $router->match($request);
                    if ($actionInstance) {
                        $request->setDispatched(true);
                        $this->response->setNoCacheHeaders();
                        if ($actionInstance instanceof \Magento\Framework\App\Action\AbstractAction) {
                            $result = $actionInstance->dispatch($request);
                        } else {
                            $result = $actionInstance->execute();
                        }
                        break;
                    }
                } catch (\Magento\Framework\Exception\NotFoundException $e) {
                    $request->initForward();
                    $request->setActionName('noroute');
                    $request->setDispatched(false);
                    break;
                }
            }
        }
        \Magento\Framework\Profiler::stop('routers_match');
        if ($routingCycleCounter > 100) {
            throw new \LogicException('Front controller reached 100 router match iterations');
        }
        return $result;
    }

public function dispatch(RequestInterface $request)

{

\Magento\Framework\Profiler::start('routers_match');

$routingCycleCounter = 0;

$result = null;

while (!$request->isDispatched() && $routingCycleCounter++ < 100) {

/** @var \Magento\Framework\App\RouterInterface $router */

foreach ($this->_routerList as $router) {

try {

$actionInstance = $router->match($request);

if ($actionInstance) {

$request->setDispatched(true);

$this->response->setNoCacheHeaders();

if ($actionInstance instanceof \Magento\Framework\App\Action\AbstractAction) {

$result = $actionInstance->dispatch($request);

} else {

$result = $actionInstance->execute();

}

break;

}

} catch (\Magento\Framework\Exception\NotFoundException $e) {

$request->initForward();

$request->setActionName('noroute');

$request->setDispatched(false);

break;

}

\Magento\Framework\Profiler::stop('routers_match');

if ($routingCycleCounter > 100) {

throw new \LogicException('Front controller reached 100 router match iterations');

}

return $result;

}

In the method dispatch() as well as in Magento 1 file app/code/core/Mage/Core/Controller/Varien/Front.php there are some matches:

Checking is a request by dispatcher ($request->isDispatched());
Searching for matches ($router->match($request)).

In comparison with Magento 1, there are only two routings determined in Magento 2:

/vendor/magento/framework/App/Router/Base.php;
/vendor/magento/framework/App/Router/DefaultRouter.php.

The same as in Magento 1, after 100 iterations if a router is not found, there will be a message displayed. Here we can find attributes of Magento 1:

if ($routingCycleCounter > 100) {
            throw new \LogicException('Front controller reached 100 router match iterations');
        }

if ($routingCycleCounter > 100) {

throw new \LogicException('Front controller reached 100 router match iterations');

}

The main steps of routing process are the same as in Magento 1:

Determining module
Determining controller
Action for detection
Data for current request detection

Router initialization in Magento 2 differs from Magento 1:

protected function _getRoutes($scope = null)
    {
        $scope = $scope ?: $this->_configScope->getCurrentScope();
        if (isset($this->_routes[$scope])) {
            return $this->_routes[$scope];
        }
        $cacheId = $scope . '::' . $this->_cacheId;
        $cachedRoutes = unserialize($this->_cache->load($cacheId));
        if (is_array($cachedRoutes)) {
            $this->_routes[$scope] = $cachedRoutes;
            return $cachedRoutes;
        }

        $routers = $this->_reader->read($scope);
        $routes = $routers[$this->_areaList->getDefaultRouter($scope)]['routes'];
        $this->_cache->save(serialize($routes), $cacheId);
        $this->_routes[$scope] = $routes;
        return $routes;
    }

public function read($scope = null)
{
	$scope = $scope ?: $this->_defaultScope;
	$fileList = $this->_fileResolver->get($this->_fileName, $scope);
	if (!count($fileList)) {
		return [];
	}
	$output = $this->_readFiles($fileList);

	return $output;
}

protected function _getRoutes($scope = null)

{

$scope = $scope ?: $this->_configScope->getCurrentScope();

if (isset($this->_routes[$scope])) {

return $this->_routes[$scope];

}

$cacheId = $scope . '::' . $this->_cacheId;

$cachedRoutes = unserialize($this->_cache->load($cacheId));

if (is_array($cachedRoutes)) {

$this->_routes[$scope] = $cachedRoutes;

return $cachedRoutes;

}

$routers = $this->_reader->read($scope);

$routes = $routers[$this->_areaList->getDefaultRouter($scope)]['routes'];

$this->_cache->save(serialize($routes), $cacheId);

$this->_routes[$scope] = $routes;

return $routes;

}

public function read($scope = null)

{

$scope = $scope ?: $this->_defaultScope;

$fileList = $this->_fileResolver->get($this->_fileName, $scope);

if (!count($fileList)) {

return [];

}

$output = $this->_readFiles($fileList);

return $output;

}

Initialization occurs when searching for an appropriate router:

…
while (!$request->isDispatched() && $routingCycleCounter++ < 100) {
            /** @var \Magento\Framework\App\RouterInterface $router */
            foreach ($this->_routerList as $router) {
                try {
                    $actionInstance = $router->match($request);
                    if ($actionInstance) {
			…

…

while (!$request->isDispatched() && $routingCycleCounter++ < 100) {

/** @var \Magento\Framework\App\RouterInterface $router */

foreach ($this->_routerList as $router) {

try {

$actionInstance = $router->match($request);

if ($actionInstance) {

…

Further routing process resembles Magento 1:

Partner With Us Let's discuss how to grow your business. Get a Free Quote.

Talk to Andrey

protected function parseRequest(\Magento\Framework\App\RequestInterface $request)
    {
        $output = [];

        $path = trim($request->getPathInfo(), '/');

        $params = explode('/', $path ? $path : $this->pathConfig->getDefaultPath());
        foreach ($this->_requiredParams as $paramName) {
            $output[$paramName] = array_shift($params);
        }

        for ($i = 0, $l = sizeof($params); $i < $l; $i += 2) {
            $output['variables'][$params[$i]] = isset($params[$i + 1]) ? urldecode($params[$i + 1]) : '';
        }
        return $output;
    }

protected function parseRequest(\Magento\Framework\App\RequestInterface $request)

{

$output = [];

$path = trim($request->getPathInfo(), '/');

$params = explode('/', $path ? $path : $this->pathConfig->getDefaultPath());

foreach ($this->_requiredParams as $paramName) {

$output[$paramName] = array_shift($params);

}

for ($i = 0, $l = sizeof($params); $i < $l; $i += 2) {

$output['variables'][$params[$i]] = isset($params[$i + 1]) ? urldecode($params[$i + 1]) : '';

}

return $output;

}

The first three elements are considered as main. They define a module, controller, and action for a current request.

Then module is determined from its moduleFrontName:

/**
         * Searching router args by module name from route using it as key
         */
        $modules = $this→_routeConfig→getModulesByFrontName($moduleFrontName);

/**

* Searching router args by module name from route using it as key

$modules = $this→_routeConfig→getModulesByFrontName($moduleFrontName);

Then a controller and action for a current request are determined:

 /**
         * Going through modules to find appropriate controller
         */
        $currentModuleName = null;
        $actionPath = null;
        $action = null;
        $actionInstance = null;

        $actionPath = $this->matchActionPath($request, $params['actionPath']);
        $action = $request->getActionName() ?: ($params['actionName'] ?: $this->_defaultPath->getPart('action'));
        $this->_checkShouldBeSecure($request, '/' . $moduleFrontName . '/' . $actionPath . '/' . $action);

        foreach ($modules as $moduleName) {
            $currentModuleName = $moduleName;

            $actionClassName = $this->actionList->get($moduleName, $this->pathPrefix, $actionPath, $action);
            if (!$actionClassName || !is_subclass_of($actionClassName, $this->actionInterface)) {
                continue;
            }

            $actionInstance = $this->actionFactory->create($actionClassName);
            break;
        }

        if (null == $actionInstance) {
            $actionInstance = $this->getNotFoundAction($currentModuleName);
            if ($actionInstance === null) {
                return null;
            }
            $action = 'noroute';
        }

/**

* Going through modules to find appropriate controller

$currentModuleName = null;

$actionPath = null;

$action = null;

$actionInstance = null;

$actionPath = $this->matchActionPath($request, $params['actionPath']);

$action = $request->getActionName() ?: ($params['actionName'] ?: $this->_defaultPath->getPart('action'));

$this->_checkShouldBeSecure($request, '/' . $moduleFrontName . '/' . $actionPath . '/' . $action);

foreach ($modules as $moduleName) {

$currentModuleName = $moduleName;

$actionClassName = $this->actionList->get($moduleName, $this->pathPrefix, $actionPath, $action);

if (!$actionClassName || !is_subclass_of($actionClassName, $this->actionInterface)) {

continue;

}

$actionInstance = $this->actionFactory->create($actionClassName);

break;

}

if (null == $actionInstance) {

$actionInstance = $this->getNotFoundAction($currentModuleName);

if ($actionInstance === null) {

return null;

}

$action = 'noroute';

}

Besides, it is checked whether the connection is safe if there is a controller file, as well as previous realization, is stored:

$this->_checkShouldBeSecure($request, '/' . $moduleFrontName . '/' . $actionPath . '/' . $action);

1	$this->_checkShouldBeSecure($request, '/' . $moduleFrontName . '/' . $actionPath . '/' . $action);

It implies that route is processed. Module, controller, and action are determined. Moreover, an action for a current request is being processed.

// set values only after all the checks are done
        $request->setModuleName($moduleFrontName);
        $request->setControllerName($actionPath);
        $request->setActionName($action);
        $request->setControllerModule($currentModuleName);
        $request->setRouteName($this->_routeConfig->getRouteByFrontName($moduleFrontName));
        if (isset($params['variables'])) {
            $request->setParams($params['variables']);
        }
        return $actionInstance;

// set values only after all the checks are done

$request->setModuleName($moduleFrontName);

$request->setControllerName($actionPath);

$request->setActionName($action);

$request->setControllerModule($currentModuleName);

$request->setRouteName($this->_routeConfig->getRouteByFrontName($moduleFrontName));

if (isset($params['variables'])) {

$request->setParams($params['variables']);

}

return $actionInstance;

Control element returns for performing action:

…
		if ($actionInstance) {
                        $request->setDispatched(true);
                        $this->response->setNoCacheHeaders();
                        if ($actionInstance instanceof \Magento\Framework\App\Action\AbstractAction) {
                            $result = $actionInstance->dispatch($request);
                        } else {
                            $result = $actionInstance->execute();
                        }
                        break;
                    }
		...
