How to Create a Shipping Module for Prestashop

How to Create Shipping Module for Prestashop

Today, we’ll show you how to create a module for the shipping service. The main peculiarity is that such module should be inherited from the abstract class CarrierModule and should implement the following 2 methods: «getOrderShippingCost», «getOrderShippingCostExternal»:

abstract class CarrierModuleCore extends Module
{
	abstract public function getOrderShippingCost($params, $shipping_cost);
	abstract public function getOrderShippingCostExternal($params);
}

abstract class CarrierModuleCore extends Module

{

abstract public function getOrderShippingCost($params, $shipping_cost);

abstract public function getOrderShippingCostExternal($params);

}

These methods are required to calculate shipping costs. We will create a shipping module to better understand all the nuances. Let’s begin:

public function install()
{
	if (parent::install()) {
		foreach ($this->_hooks as $hook) {
			if (!$this->registerHook($hook)) {
				return FALSE;
			}
		}

		if (!$this->createCarriers()) { //function for creating new currier
			return FALSE;
		}

		return TRUE;
	}

	return FALSE;
}

public function install()

{

if (parent::install()) {

foreach ($this->_hooks as $hook) {

if (!$this->registerHook($hook)) {

return FALSE;

}

if (!$this->createCarriers()) { //function for creating new currier

return FALSE;

}

return TRUE;

}

return FALSE;

}

Here we use the standard constructor, and we are going to use only one hook “асtiоnCаrrierUpdаte”. This hook is required to ensure that the module will not lose connection with the carrier, created by the module. The thing is that a carrier is given a new ID each time it is edited through the admin panel. Users do not notice this, but for the program this is very important, because ID serves as a unique identifier, which we can use to find the necessary carrier at any time.

class belvg_studyshipping extends CarrierModule
{
const PREFIX = 'belvg_studyshipping_';

protected $_hooks = array(
	'actionCarrierUpdate', //For control change of the carrier's ID (id_carrier), the module must use the updateCarrier hook.
);

protected $_carriers = array(
//"Public carrier name" => "technical name",
	'My new carrier' => 'belvgstudy',
);

public function __construct()
{
	$this->name = 'belvg_studyshipping';
	$this->tab = 'shipping_logistics';
	$this->version = '1.6.1';
	$this->author = 'BelVG';
	$this->bootstrap = TRUE;

	parent::__construct();

	$this->displayName = $this->l('Belvg Shipping');
	$this->description = $this->l('How to create shipping module.');
}

class belvg_studyshipping extends CarrierModule

{

const PREFIX = 'belvg_studyshipping_';

protected $_hooks = array(

'actionCarrierUpdate', //For control change of the carrier's ID (id_carrier), the module must use the updateCarrier hook.

);

protected $_carriers = array(

//"Public carrier name" => "technical name",

'My new carrier' => 'belvgstudy',

);

public function __construct()

{

$this->name = 'belvg_studyshipping';

$this->tab = 'shipping_logistics';

$this->version = '1.6.1';

$this->author = 'BelVG';

$this->bootstrap = TRUE;

parent::__construct();

$this->displayName = $this->l('Belvg Shipping');

$this->description = $this->l('How to create shipping module.');

}

When installing the module we also create a carrier and assign it to the module. This way the carrier will be receiving the shipping costs not from a static database, but dynamically, perhaps, by using a third-party API. It is important to keep the ID and reference of the carrier, because we are going to identify the carrier exactly by that field when the ID changes.

Partner With Us Let's discuss how to grow your business. Get a Free Quote.

Talk to Tatiana

protected function createCarriers()
{
	foreach ($this->_carriers as $key => $value) {
		//Create new carrier
		$carrier = new Carrier();
		$carrier->name = $key;
		$carrier->active = TRUE;
		$carrier->deleted = 0;
		$carrier->shipping_handling = FALSE;
		$carrier->range_behavior = 0;
		$carrier->delay[Configuration::get('PS_LANG_DEFAULT')] = $key;
		$carrier->shipping_external = TRUE;
		$carrier->is_module = TRUE;
		$carrier->external_module_name = $this->name;
		$carrier->need_range = TRUE;

		if ($carrier->add()) {
			$groups = Group::getGroups(true);
			foreach ($groups as $group) {
				Db::getInstance()->autoExecute(_DB_PREFIX_ . 'carrier_group', array(
					'id_carrier' => (int) $carrier->id,
					'id_group' => (int) $group['id_group']
				), 'INSERT');
			}

			$rangePrice = new RangePrice();
			$rangePrice->id_carrier = $carrier->id;
			$rangePrice->delimiter1 = '0';
			$rangePrice->delimiter2 = '1000000';
			$rangePrice->add();

			$rangeWeight = new RangeWeight();
			$rangeWeight->id_carrier = $carrier->id;
			$rangeWeight->delimiter1 = '0';
			$rangeWeight->delimiter2 = '1000000';
			$rangeWeight->add();

			$zones = Zone::getZones(true);
			foreach ($zones as $z) {
				Db::getInstance()->autoExecute(_DB_PREFIX_ . 'carrier_zone',
					array('id_carrier' => (int) $carrier->id, 'id_zone' => (int) $z['id_zone']), 'INSERT');
				Db::getInstance()->autoExecuteWithNullValues(_DB_PREFIX_ . 'delivery',
					array('id_carrier' => $carrier->id, 'id_range_price' => (int) $rangePrice->id, 'id_range_weight' => NULL, 'id_zone' => (int) $z['id_zone'], 'price' => '0'), 'INSERT');
				Db::getInstance()->autoExecuteWithNullValues(_DB_PREFIX_ . 'delivery',
					array('id_carrier' => $carrier->id, 'id_range_price' => NULL, 'id_range_weight' => (int) $rangeWeight->id, 'id_zone' => (int) $z['id_zone'], 'price' => '0'), 'INSERT');
			}

			copy(dirname(__FILE__) . '/views/img/' . $value . '.jpg', _PS_SHIP_IMG_DIR_ . '/' . (int) $carrier->id . '.jpg'); //assign carrier logo

			Configuration::updateValue(self::PREFIX . $value, $carrier->id);
			Configuration::updateValue(self::PREFIX . $value . '_reference', $carrier->id);
		}
	}

	return TRUE;
}

protected function createCarriers()

{

foreach ($this->_carriers as $key => $value) {

//Create new carrier

$carrier = new Carrier();

$carrier->name = $key;

$carrier->active = TRUE;

$carrier->deleted = 0;

$carrier->shipping_handling = FALSE;

$carrier->range_behavior = 0;

$carrier->delay[Configuration::get('PS_LANG_DEFAULT')] = $key;

$carrier->shipping_external = TRUE;

$carrier->is_module = TRUE;

$carrier->external_module_name = $this->name;

$carrier->need_range = TRUE;

if ($carrier->add()) {

$groups = Group::getGroups(true);

foreach ($groups as $group) {

Db::getInstance()->autoExecute(_DB_PREFIX_ . 'carrier_group', array(

'id_carrier' => (int) $carrier->id,

'id_group' => (int) $group['id_group']

), 'INSERT');

}

$rangePrice = new RangePrice();

$rangePrice->id_carrier = $carrier->id;

$rangePrice->delimiter1 = '0';

$rangePrice->delimiter2 = '1000000';

$rangePrice->add();

$rangeWeight = new RangeWeight();

$rangeWeight->id_carrier = $carrier->id;

$rangeWeight->delimiter1 = '0';

$rangeWeight->delimiter2 = '1000000';

$rangeWeight->add();

$zones = Zone::getZones(true);

foreach ($zones as $z) {

Db::getInstance()->autoExecute(_DB_PREFIX_ . 'carrier_zone',

array('id_carrier' => (int) $carrier->id, 'id_zone' => (int) $z['id_zone']), 'INSERT');

Db::getInstance()->autoExecuteWithNullValues(_DB_PREFIX_ . 'delivery',

array('id_carrier' => $carrier->id, 'id_range_price' => (int) $rangePrice->id, 'id_range_weight' => NULL, 'id_zone' => (int) $z['id_zone'], 'price' => '0'), 'INSERT');

Db::getInstance()->autoExecuteWithNullValues(_DB_PREFIX_ . 'delivery',

array('id_carrier' => $carrier->id, 'id_range_price' => NULL, 'id_range_weight' => (int) $rangeWeight->id, 'id_zone' => (int) $z['id_zone'], 'price' => '0'), 'INSERT');

}

copy(dirname(__FILE__) . '/views/img/' . $value . '.jpg', _PS_SHIP_IMG_DIR_ . '/' . (int) $carrier->id . '.jpg'); //assign carrier logo

Configuration::updateValue(self::PREFIX . $value, $carrier->id);

Configuration::updateValue(self::PREFIX . $value . '_reference', $carrier->id);

}

return TRUE;

}

When removing the module also delete the carrier.

protected function deleteCarriers()
{
	foreach ($this->_carriers as $value) {
		$tmp_carrier_id = Configuration::get(self::PREFIX . $value);
		$carrier = new Carrier($tmp_carrier_id);
		$carrier->delete();
	}

	return TRUE;
}

public function uninstall()
{
	if (parent::uninstall()) {
		foreach ($this->_hooks as $hook) {
			if (!$this->unregisterHook($hook)) {
				return FALSE;
			}
		}

		if (!$this->deleteCarriers()) {
			return FALSE;
		}

		return TRUE;
	}

	return FALSE;
}

protected function deleteCarriers()

{

foreach ($this->_carriers as $value) {

$tmp_carrier_id = Configuration::get(self::PREFIX . $value);

$carrier = new Carrier($tmp_carrier_id);

$carrier->delete();

}

return TRUE;

}

public function uninstall()

{

if (parent::uninstall()) {

foreach ($this->_hooks as $hook) {

if (!$this->unregisterHook($hook)) {

return FALSE;

}

if (!$this->deleteCarriers()) {

return FALSE;

}

return TRUE;

}

return FALSE;

}

Implementing the functions of the abstract class CarrierModule. We are not going to focus attention on any logic for dynamic calculation of the cost, but will just return the amount of 777.

public function getOrderShippingCost($params, $shipping_cost)
{
	return 777;
}

public function getOrderShippingCostExternal($params)
{
	return $this->getOrderShippingCost($params, 0);
}

public function getOrderShippingCost($params, $shipping_cost)

{

return 777;

}

public function getOrderShippingCostExternal($params)

{

return $this->getOrderShippingCost($params, 0);

}

The hook «ActionCarrierUpdate» keeps the reference of the original carrier.

public function hookActionCarrierUpdate($params)
{
	if ($params['carrier']->id_reference == Configuration::get(self::PREFIX . 'swipbox_reference')) {
		Configuration::updateValue(self::PREFIX . 'swipbox', $params['carrier']->id);
	}
}

public function hookActionCarrierUpdate($params)

{

if ($params['carrier']->id_reference == Configuration::get(self::PREFIX . 'swipbox_reference')) {

Configuration::updateValue(self::PREFIX . 'swipbox', $params['carrier']->id);

}

So, this is the entire module. When developing such a module the main part of the work takes to receive data via API and to develop the logic for calculating the cost of delivery.
