Folder Structure in Magento 2

Nov 15, 2018

2531 Yaroslav Tobolich

Folder Structure in Magento 2

This article will deal with the topic of the folder structure in Magento 2 theme. I will describe the folders and their functions and show you which folders are extremely useful for theme development and which ones are optional.

Which folders can a theme contain?
Which folders are folders are optional and which are required?
What is the purpose of each of the folders?

Which folders can a theme contain?

A certain theme can contain the folders for the extension of module styles, etc folder, i18n, media and web. The web folder, in its turn, contains css, js, fonts, images, template folders. You can see the graphic structure of a theme on the picture below; I decided to use the blank theme as an example.

Folder structure in Magento 2

Which folders are optional and which are required?



Folder Required or optional Example
/<name_Vendor>_<name_Module> optional Magento_Theme, Magento_Catalog, Magento_Checkout and other
/<name_Vendor>_<name_Module>/layout optional Magento_Catalog/layout
/<name_Vendor>_<name_Module>/layout/base optional Magento_Catalog/layout/base
/<name_Vendor>_<name_Module>/templates optional Magento_Catalog/templates
/<name_Vendor>_<name_Module>/email optional Magento_Sales/email
/<name_Vendor>_<name_Module>/email/i18n optional Magento_Customer/email/i18n/ar_SA
/etc required if there is no parent theme /app/design/frontend/Magento/blank/etc
/i18n optional /app/design/frontend/Magento/blank/i18n
/media required /app/design/frontend/BelVG/caskers_theme/media
/web optional This folder I’ll describe in more detail later in the article
Igor Dragun

Partner With Us

Let's discuss how to grow your business. Get a Free Quote.
Talk to Igor

Let’s take a look at the web folder. I decided to draw your attention  to this very folder since it may be located in the folder that extends the module. I will explain you how everything works in Magento_Checkout using this module as an example. Now take a look at the table below:

Folder Folder description
/<name_Vendor>_<name_Module>/web/css This folder as a rule contains CSS and Less files.

Example: /Magento_Checkout/web/css

/<name_Vendor>_<name_Module>/web/js This folder as a rule contains JS files.

Example: /Magento_Checkout/web/js

/<name_Vendor>_<name_Module>/web/template This folder as a rule contains templates for JS components and widgets. The file format is .html.

Example: /Magento_Checkout/web/template

/<name_Vendor>_<name_Module>/web/templates This folder as a rule contains templates for JS components and widgets. The file format is .html.

Example: /Magento_Checkout/web/template

/<name_Vendor>_<name_Module>/web/i18n This folder as a rule contains localized folders for the module, such as css/, js/, etc.

Example: Magento_Customer/web/i18n/ar_SA/js/

/<theme_dir>/web/i18n I mentioned this folder earlier, but here this folder is not for the module, but for the theme. As a rule, it contains localized folders and themes, such as css/, js/, etc.

Example: /app/design/frontend/Magento/blank/web/i18n/ar_SA/css/source/_extend.less

/<theme_dir>/web/css I mentioned this folder earlier, but here this folder is not for the module, but for the theme.  As a rule, it contains .less variable style files.

Example: /app/design/frontend/Magento/blank/web/css

/<theme_dir>/web/fonts This folder as a rule contains font files.

Example: /app/design/frontend/Magento/luma/web/fonts

/<theme_dir>/web/images This folder contains image files for the theme of various sprites, theme logo, etc.

Example: /app/design/frontend/Magento/luma/web/images

/<theme_dir>/web/mage This folder contains files of Magento libraries such as jquery, jqueryui and various cms widgets. I do not recommend using this folder to replace components. Use requireJS instead.

What is each folder responsible for?



Folder Folder description
/<name_Vendor>_<name_Module> This folder contains templates, layouts and the we folder.
/<name_Vendor>_<name_Module>/layout This folder contains layout extending files.

Examples: default.xml, default_head_blocks.xml, catalog_category_view.xml

/<name_Vendor>_<name_Module>/layout/base This folder contains layout files, which override basic layouts.
/<name_Vendor>_<name_Module>/templates This folder contains template files.
/<name_Vendor>_<name_Module>/email This folder contains email template files.
/<name_Vendor>_<name_Module>/email/18n This folder contains localized email template files.
/etc This folder contains the view.xml configuration file.
/i18n This folder .csv translations.
/media This folder theme preview image.
/web I’ve already mentioned this folder above.



As you can see, various folders are used for the theme development in Мagento 2, and each one is responsible for its technology stack and its module. Besides, you can always expand any module using the layout, JS and CSS folders.
